AG- 77 HD
Talius’ large-format roll shutter — engineered for garage doors, two-story atrium windows, oversized storefronts and true rolling-door applications where standard mini-profiles run out of width or height.
Why It Fits
When standard mini-profiles run out of width or height.
A 16-foot-wide garage door. A 13-foot-tall storefront window. A loading dock that needs both width and height. These openings exceed the maximum dimensions of most residential-grade roll shutter profiles.
AG-77 HD addresses the gap between residential roll shutters and heavy industrial doors. The “AG” designation marks it as successor to the Talius Shield Standard; “77” refers to the 77 mm (≈3″) cover height — significantly larger than the 37–45 mm range of HQ Macro, Shield Mini and Safe Mini.
Anatomy
Seven components. Engineered for large-format performance.
01
Curtain Profile
Large-format, roll-formed aluminum slats with a polyurethane foam core.
02
Panel Box
Precision roll-formed aluminum housing that contains the rolled curtain and shaft.
03
GR-105 Guide Rails
Heavy-duty extruded aluminum rails fitted with side locks and weather stripping.
04
Bottom Profile
Extruded aluminum bar that seals the curtain when fully closed.
05
Rolling Carriage Assembly
Shifts forward/backward as the curtain raises or lowers — adjusts to the changing roll-up diameter.
06
Built-in Locking Mechanism
Integrated into the system. No external locks required, none compatible.
07
Operator
Manual crank or motorized — Standard limit or Somfy RTS.
Technical Specifications
The numbers dealers need to specify large openings.
| SPECIFICATION | DETAIL |
|---|---|
| Cover Height | 3" (77 mm) |
| Slat Thickness | 0.75" (19 mm) |
| Wall Thickness | 0.0244" (0.62 mm) |
| Slats per Height | 0.33 / inch (13 / m) |
| Weight per Area | 0.0066 lbs/in² (4.64 kg/m²) |
| Finish | Enamel 0.0020" (0.05 mm) |
| Core Material | Polyurethane hard foam |
| Max Width (A2) with Panel Box | 21.3 ft (6.5 m) |
| Max Width (A2) without Panel Box | 22.97 ft (7.0 m) |
| Max Height (B1) | 16.4 ft (5.0 m) |
| Max Area | 215.28 ft² (20.0 m²) |
Critical note for dealers
You must comply with the maximum area. Dimensions greater than the maximum height may be exceeded with certain restrictions. Always verify operator lifting capacity — motor torque requirements increase with both width and height.
- Key Differentiator
The Rolling Carriage Assembly.
As the curtain rolls up, the diameter on the shaft grows — changing the geometry between curtain and rails. Standard fixed carriages bind or create friction. AG-77 HD solves this with a carriage that shifts forward or backward as the curtain moves, automatically adjusting to the changing roll-up diameter.
Smooth full-height operation
Curtain stays aligned across the full 16.4-foot height without binding.
Reduced wear
Less friction on guide rails and slats means a longer service life vs. fixed-carriage designs.
Consistent alignment
Prevents jamming as the roll diameter changes on the shaft.
Lower motor strain
Motors do not have to fight binding geometry — fewer service calls for garage door clients.
GR-105 Guide Rails
Built for large openings, not just for show.
Standard PRO or SAFE rails are not sufficient for AG-77 HD. Talius specifies the GR-105 — an extruded aluminum guide rail designed specifically for this profile. The wider rail provides the structural stability required for large, heavy curtains. Side locks hook inside the rails to keep the curtain in alignment during high winds or forced-entry attempts. It is not a cosmetic feature — it is an engineering requirement.
| FEATURE | SPECIFICATION |
|---|---|
| Overall Width | 4-3/16" (105 mm) |
| Channel Depth | 1-3/8" (35 mm) |
| Wall Thickness | 1/4" (31 mm) nominal |
| Side Locks | Included, hook inside the rail |
| Weather Stripping | Fitted as standard |
B2B Applications
Where AG-77 HD excels.
Garage Doors
Residential & Commercial Garages
Standard mini-profiles max out at 14–16 ft. AG-77 HD spans 8–18 ft garage doors comfortably with headroom up to 21.3 ft. The 3″ slat creates visual scale appropriate for big openings — small slats on big doors look out of proportion.
Large Windows & Doors
Atriums & Storefronts
Floor-to-ceiling windows, sliding glass doors and commercial storefronts often exceed 10 ft tall. AG-77 HD covers up to 16.4 ft tall and 215 ft² — accommodating two-story atriums and tall commercial entrances.
Rolling Doors
Industrial & Internal
Designed for true rolling-door use — warehouse partitions, loading dock separators, retail security gates and industrial machine enclosures. Built-in locking + GR-105 rails provide the structural integrity for ground-level traffic and impact.
Specific rolling-door use cases include warehouse internal partitions, loading dock separators, retail security gates and industrial machine enclosures.
- Energy Efficiency
Large glass = large thermal liability.
- 30–50% of HVAC load on big windows
A two-story window wall can account for 30–50% of a building’s heating and cooling load. The polyurethane foam core in AG-77 HD provides insulation against both heat gain and heat loss — blocking solar heat before it enters in summer and trapping indoor heat in winter.
For commercial clients, that translates to lower utility bills. For residential clients with large glass areas, it means comfort in rooms that were previously too hot in summer or too cold in winter.
Key Differentiator
Vandalism protection that sets it apart from HQ Macro.
Built to resist scratching with keys, kicks, thrown bottles or rocks, and attempts to pry the bottom profile — the everyday risks faced by storefronts in urban areas.
What this means for dealers
- One less component to specify
- No compatibility issues with motorized operation
- Locking is automatic and concealed
- Cannot be bypassed by external tampering
Compatibility warning
AG-77 is not compatible with any other locking device. Do not attempt to add hanger locks, centre key locks or sliding bars — they will interfere with the built-in mechanism.
Configure Your Spec
Colours and operators.
- Colours
White
Beige
Brown
Black
silver
Plus 1,800+ custom colours from the Benjamin Moore fan deck — applied to curtain (both sides or one), rails, bottom profile, sills, build-up and panel box. Custom price decreases per unit at higher quantity. No upcharge on aluminum build-up tubing.
*Beige availability — verify with Channel Sales.
- Operators
manual
• Gear with crank rod (68″)
• Min. A2 = 20″ (51 cm)
• Smaller units only
Motorized
• Standard limit (120 VAC / 60 Hz)
• Somfy RTS (programmable)
• Manual override option
Given the large size and weight of the curtain, motorized operation is strongly recommended for most AG-77 HD applications.
Add the Motor Preparation Package with manual units to make future motorization simple — only the motor and switch need to be added later.
- Guide Rails`
250 mm
360 mm
Ensure sufficient room above the guide rails. Bottom profile protrudes ~2″ (50 mm) below the box when fully rolled up.
Installation Requirements
Five rules that prevent callbacks.
01
Use the correct dimension
Talius price grids use A2 (width including guide rails). GR-105 rails are wide — confirm your opening accommodates the full A2 width.
02
Account for panel box headroom
Panel box height depends on shaft size — 250 mm (9.8″) for the 70 shaft, 360 mm (14.2″) for the 114 shaft. The bottom profile protrudes ~2″ (50 mm) below the box when fully rolled up.
03
AG-77 cannot use Hanger Locks
The uilt-in locking mechanism is integral. Do not add external locks — the B1 chart in the price book explicitly notes “(Can not be installed with Hanger Locks).”
04
Single span only
AG-77 and SAFE View are single span units only — they cannot be split into multiple curtain sections like HQ Macro, Shield Mini, or Safe Mini.
05
Winterization is available
For installations in climates with freezing temperatures, the same Winterization Package adds panel box reinforcement and bottom-profile surface stoppers.
- Cold-climate installations? Add the Winterization Package
Why Partner With Talius
40 years. One facility. Salmon Arm, BC.
Talius has manufactured exterior protection systems in North America for over 40 years. Their Salmon Arm facility handles roll-forming, assembly, and quality control under one roof — an engineered system backed by a manufacturer that understands North American building codes, weather and installation practices.
Made-to-order manufacturing
No stockholding. Each unit built to exact width and height.
GR-105 guide rails
Included, with side locks and weather stripping.
Rolling carriage assembly
Standard on all AG-77 HD units.
Built-in locking mechanism
No separate lock to specify or install.
Operator flexibility
Manual, standard motor, or Somfy RTS motor.
Custom colours
Over 1,800 Benjamin Moore options.
Partner Zone access
CAD drawings, installation guides, wiring diagrams, technical specs.
Channel sales support
Direct technical experts for project-specific questions.
FAQ
Frequently Asked Questions
Common AG-77 HD questions from dealers, specifiers, and installers.
01 How does AG-77 HD differ from SAFE Mini or SHIELD Mini?
02 What is the maximum size for AG-77 HD?
03 Is AG-77 HD suitable for high-wind areas?
04 Can AG-77 HD be motorized?
05 What is the lead time for custom colours or large units?
Conclusion
Say yes to large-opening projects.
The market for roll shutters is not one-size-fits-all. Installing a standard mini-profile on an 18-foot-wide garage door exceeds the product’s engineering limits. Telling a client with a two-story window wall that your products max out at 10 feet loses the sale.
AG-77 HD fills that gap — large-format coverage (21.3 ft wide, 16.4 ft tall), medium-duty vandalism protection, energy efficiency and smooth operation via the rolling carriage assembly. Offer SAFE Mini for high-security applications. Offer AG-77 HD when the opening is simply too big for anything else.
